Compact and versatile four-sided planer / moulder
The MP260 four-sided planer / moulder is a versatile, compact machine engineered for professional woodworkers, carpenters, or joiners in the construction trade. Affordable and easy to use, the MP260 planes and moulds boards on all four sides in a single pass into a variety of professionally finished products including flooring, planed boards, crown moulding, cabinet trim, paneling, door and window frames, and furniture components.
Centralized Control Panel
Allows the operator to start/stop all 4 cutter and power feed motors separately.
Adjustable Table Height
The table height is easily adjusted with a manual hand crank.
Easy-to-change Knife Profiles
Changing knives is simple and takes approximately 10 to 20 minutes.
Variable Feed Rate
Is adjustable from 2 - 11 m/min.
Five Feed Rollers
4 Steel and 1 Polyurethane Rollers.
| 4-sided processing | |
|---|---|
| Planing Width | 40-260 mm |
| Planing Height | 10-100 mm |
| Min. Material Length | 450 mm |
| 2-sided processing | |
| Planing Width | 10-300 mm |
| Planing Height | 10-220 mm |
| Min. Material Length | 450 mm |
| 1-sided processing | |
| Planing Width | 10-410 mm |
| Planing Height | 10-250 mm |
| Min. Material Length | 450 mm |
| Top Horizontal Cutterhead | |
| Diameter | 72 mm |
| Width | 410 mm |
| Power | 3 kW |
| Max. Planing Depth | 5 mm |
| Max. Moulding Depth | 20 mm |
| Bottom Horizontal Cutterhead | |
| Diameter | 72 mm |
| Width | 300 mm |
| Power | 3 kW |
| Max. Planing Depth | 4 mm |
| Max. Moulding Depth | 8 mm |
| Side Cutterheads | |
| Spindle Diameter | 30 mm |
| Max. Height | 100 mm |
| Max. Diameter | 140 mm |
| Power | 3 kW |
| Max. Planing Depth | 5 mm |
| Max. Moulding Depth | 20 mm |
| Power | |
| Total Power | 12.5 kW |
| Power Requirements | 3-phase, 400 V, 50 Hz, 27.45 A (ECO) 3-phase, 400 V, 50 Hz, 28.8 A (PRO) |
| Feed System | |
| Power | 0.18 kW (ECO) 0.37 kW (PRO) |
| Feed Speed | 8 m/min (ECO) 2-11 m/min (PRO) |
| Dust Collection Specifications | |
| Dust Extraction Ports | 1x 125 mm 3x 100 mm |
| Recommended Airflow | 4000 m3/h |
