LX50SUPER Sawmill
Experience the legendary reliability and durability of Wood-Mizer sawmills, now available at a record-low price. Order the LX50SUPER sawmill today and start your adventure in woodworking!
- 2-Year Sawmill Warranty
- Made in Europe
- Rigid xFRAME Mast
- Head up/down
Click here to see all the changes.
- The operator’s position on the right side, sawdust outlet stayed on the left side.
- Rectangle-shaped sawhead throat with no bevels.
- Sawhead cover locking with metal latches.
2-year warranty
made in eu
service support
free shipping
The LX50 sawmill series are the most compact and budget-friendly Wood-Mizer machines for processing logs into lumber individually. Their popularity results from the perfect connection of simple design and proven mechanical solutions, combined with the quality and durability characteristic of legendary Wood-Mizer sawmills. The LX50 series is ideal for novice sawyers and hobbyists who expect efficient and precise wood processing for their own needs.
The LX50SUPER sawmill allows users to process logs up to 66 cm in diameter and a maximum length of 3,70 m, which can be customized to meet user needs by expanding the bed with additional segments measuring 1,53 m each.
In the LX50SUPER sawmill, the standard bed equipment includes two folding side supports adjusted on a rod, 2 log clamps, six cross-sections with reinforcements, and adjustable legs. Various accessories can be ordered for the sawmill, including bed extension segments, additional supports and clamps, log loading ramps, a wedge for compensating log taper, and a cant hook.
The operation of the LX50START sawmill is ergonomic and intuitive - the operator manually adjusts the sawhead height using a crank and smoothly moves the sawhead along the bed on rollers. The LX50START sawmill features a blade cleaning system with a manual valve and a blade tensioning system based on a screw with an indicator. The blade guide rollers ensure the stability of the blade, allowing for precise cutting.
The LX50SUPER sawmill utilizes a Kohler G14 (14 HP) gasoline engine or an EH5 (4 kW) electric motor. Kohler engines, renowned for their high operational quality and reliability, are employed for superior sawmill performance.
The product comes with a two-year warranty and access to professional technical support.
The LX50SUPER sawmill includes free shipping in the EU and is delivered on a compact pallet measuring 165 x 65 x 98 cm. Assembly and initial setup are explained in an instructional video available online.
| Power | |
|---|---|
| Power | 5.5 kW Electric 14 HP Petrol (KOHLER Command PRO CH440) |
| Cutting Capacity | |
| Max. Log Diameter | 66 cm |
| Max. Log Length | 3.7 m (3 segments 1.53 m each, S3 Bed) |
| Max. Width of Cut | 60 cm |
| Max. Cant Width | 55 cm |
| Max. Depth of Cut | 20 cm |
| Head Features and Options | |
| Head Up/Down | Hand Crank |
| Head Forward/Reverse | Manual Push |
| Blade Lubrication | Manual Valve |
| Blade Tension System | Screw with Indicator |
| Sawdust Collection Port Diameter | 101.6 mm (4'') |
| Additional Options | N/A |
| Blade | |
| Length | 3340 mm |
| Width | 32 mm |
| Thickness | 1.07 mm |
| Blade Wheels | |
| Blade Wheel Diameter | 400 mm |
| Blade Wheel Type | Belted |
| Blade Wheel Material | Cast Iron |
| Bed Features and Options | |
| Bed Construction | Twin Rail |
| Angled Bed Rails | N/A |
| Bed Extensions | Additional Bed Sections: 1.53 m |
| Bed Features | Adjustable Legs |
| Log Handling | |
| Manual | 2 Manual Log Clamps 2 Side Supports (Folded, adjusted on the rod) |
| STANDARD Hydraulic | N/A |
| SUPER Hydraulic | N/A |
| Sawmill Features and Options | |
| Frame Construction | xFRAME |
| Power Requirements | 3 Phases, 400 V, 50 Hz / 10.5 A (5.5 kW) |
| Standards | CE |
| Options | Log Loading Ramps Cant Hook Log Wedge |
