LT40 Sawmill
In stock
Get a personalized quote for any configurations.
Years of proven and productive sawing performance
Ruggedly constructed to withstand demanding working conditions while delivering consistent timber production.
Benefits
- High Quality Construction
- Stationary or Mobile Configurations
- Electronic Setworks boost Productivity
- Customize Bed Length & Log Handling Options
Description
LT40 Sawmill
The LT40 Sawmill Series is the backbone of thousands of successful wood processing businesses worldwide. It is ruggedly constructed to withstand demanding working conditions while delivering consistent timber production.
The LT40 cuts logs up to 90 cm in diameter and 5-8.6 m long. Manual, hydraulic, or Super Hydraulic log handling configurations are available to match productivity and budget requirements.
With the standard electronic SW Setworks, simply select the board thickness required and the head height automatically positions for each cut - no waiting for calculations. Forward and reverse movement is made by the adjustable power feed. A water tank feeds lubrication directly to the blade to improve cutting performance and keep the blade clean. The electric blade guide arm keeps the blade supported while cutting various sized material. Blade tension is easily adjusted, and keeps the blade at the proper tension for cutting. Wood-Mizer’s wide range of affordable blades are designed for all cutting requirements, and deliver maximum log yield and minimal waste of the valuable timber.
Popular Options
With the optional trailer package, the sawmill can be made fully mobile. The optional Debarker prolongs blade life by clearing away dirt and rocks from the bark. Various electric, petrol and diesel engine options are available.
Read More
Videos
LT40 Sawmill
Features
LT40 Sawmill
Specifications
LT40 Sawmill
Power | |
---|---|
Power | 11 kW (E15) Electric15 kW (E20) Electric18.5 kW Electric28 HP Petrol38 HP Petrol |
Cutting Capacity | |
Max. Log Diameter | 90 cm |
Max. Width of Cut | 72 cm |
Max. Cant Width | 63 cm |
Max. Depth of Cut | 35 cm |
Head Features and Options | |
Setworks | SW10 (for AC models)SW PLC1 (for AC models)SW PLC2 (for AC models)Accuset2 (for AC and DC models) |
Head Up/Down | Electric |
Head Forward/Reverse | Electric |
Blade Guide Arm | Electric |
Blade Lubrication | Electro ValveLubeMizer |
Blade Tension System | Hydraulic Tensioning Handle with Gauge |
Debarker | Optional |
Sawdust Collection Port Diameter | 150 mm |
Blade | |
Length | 4010 mm |
Width | 32 mm35 mm38 mm |
Thickness | 1.00 mm1.07 mm1.14 mm |
Blade Wheels | |
Blade Wheel Diameter | 483 mm |
Blade Wheel Type | Belted |
Blade Wheel Material | Cast Iron |
Bed Features and Options | |
Bed Construction | Monorail |
Angled Bed Rails | Optional |
Bed Extensions | Bed Extension: 0.5 mBed Extension: 0.9 mManual or Hydraulic Bed Extension: 1.8 m, 3.6 m or 7.2 m |
Trailer Package | Optional |
Log Handling | |
Manual | ToeboardsSide SupportClampWinch Log TurnerLog Loader (Manual Pump) |
STANDARD Hydraulic | 3 Side SupportsCentral Clamp on Two RodsLog TurnerLog Leveling RollersHold-down ClampsLog Loader |
SUPER Hydraulic | Chain Turner2 Vertical Side SupportCentral Clamp on Two RodsLog Leveling RollerPower Roller with Two CylindersHold-Down ClampsLog Loader |
Sawmill Features and Options | |
Frame Construction | Cantilever |
Standards | CE |
Options | Log DeckIncline ConveyorRoller TableTransfer DeckAbsorption Roller |
