Versatile and reliable wood processing for small business
Ideal sawmill for businesses that require efficiency, flexibility and productivity at a low price.
Benefits
- 2 Circular Blades. 1 Adjustable Blade.
Description
LT20SUPER Sawmill
The LT20SUPER Sawmill Series presents ideal solutions for start-up wood businesses, workshops, individual estates and larger business operations that require an efficient, flexible and productive sawmill but do not need the larger volume capability of the LT40 and LT70 Series.
The LT20SUPER cuts logs up to 80 cm in diameter and 4.8-8.4 m long. Log handling with the LT20SUPER can be configured for the exact needs of your business – Manual or hydraulic log handling configurations are available to match productivity and budget requirements. The LT20SUPER sawmill head retains the same productivity features of Wood-Mizer’s premium range. With the standard electronic SW Setworks, simply select the board thickness required and the head height automatically positions for each cut - no waiting for manual calculations. Forward and reverse movement is made by the adjustable power feed.
A water tank feeds lubrication directly to the blade to improve cutting performance and keep the blade clean. The electric blade guide arm keeps the blade supported while cutting various sized material. Blade tension is easily adjusted, and keeps the blade at the proper tension for cutting.
Popular Options
Full mobility for your sawmill can be achieved with the addition of a trailer package. The optional Debarker prolongs blade life by clearing away dirt and rocks from the bark. Petrol and diesel engine options available.
Read More
Videos
LT20SUPER Sawmill
Features
LT20SUPER Sawmill
Specifications
LT20SUPER Sawmill
Power | |
---|---|
Power | 11 kW (E15) Electric 15 kW (E20) Electric 25 HP Petrol 22 HP Diesel |
Cutting Capacity | |
Max. Log Diameter | 80 cm |
Max. Width of Cut | 65 cm |
Max. Cant Width | 58 cm |
Max. Depth of Cut | 25 cm |
Head Features and Options | |
Setworks | SW10 (for AC models) |
Head Up/Down | Electric |
Head Forward/Reverse | Electric |
Blade Guide Arm | Electric |
Blade Lubrication | Electro Valve |
Blade Tension System | Screw with Gauge |
Debarker | Optional |
Sawdust Collection Port Diameter | 101.6 mm (4'') |
Additional Options | Remote Operation Station (Curtain) |
Blade | |
Length | 4010 mm |
Width | 32 mm 35 mm |
Thickness | 1.00 mm 1.07 mm |
Blade Wheels | |
Blade Wheel Diameter | 483 mm |
Blade Wheel Type | Belted |
Blade Wheel Material | Cast Iron |
Bed Features and Options | |
Bed Construction | Monorail |
Angled Bed Rails | Optional |
Bed Extensions | Bed Extension: 0.5 m Bed Extension: 0.9 m Manual or Hydraulic Bed Extension: 1.8 m, 3.6 m or 7.2 m |
Trailer Package | Optional |
Bed Features | Adjustable Legs |
Log Handling | |
Manual | Toeboards Side Support Clamp Winch Log Turner Log Loader (Manual Pump) |
STANDARD Hydraulic | 3 Side Supports Central Clamp on Two Rods Claw Log Turner Log Leveling Rollers Hold-down Clamps Log Loader |
SUPER Hydraulic | Chain Turner 2 Vertical Side Support Central Clamp on Two Rods Log Leveling Roller Power Roller with Two Cylinders Hold-Down Clamps Log Loader |
Sawmill Features and Options | |
Frame Construction | Cantilever |
Standards | CE |
Options | Cant Hook Log Deck |
