LT15START Sawmill

In stock
Only %1 left

Prices do not include VAT and shipping costs.

Sawmill equipped with S3 bed (5.2 m) and manual feeds.

Select other configuration:

Configurations that are not available online can be ordered via contact form or by calling in +48 63 26 26 000.

Ultra-compact sawmill for maximum quality and affordability

An affordable sawmill for low-volume timber processing to support your business or hobby.

Benefits
  • 2 Circular Blades. 1 Adjustable Blade.
LT15

Sawmill Blades for LT15START/LT15CLASSIC

See More
Description LT15START Sawmill

The LT15START is the ideal affordable sawmill for straightforward timber processing with sturdy construction and simple features. Woodworkers, farmers, furniture makers, and builders who want to save money by producing their own sawn timber from logs will find that the LT15START will exceed their expectations for an entry-level sawmill.

The LT15START cuts logs up to 70 cm in diameter and 5.4 m long with the standard bed. In order to cut longer logs, bed extensions can be added to extend the sawmill bed to any required cutting length.

The sawmill features push feed and a manual crank for repositioning the blade for the next cut.

Thin-kerf blades require minimal energy consumption, so a 5.5 kW electric motor provides sufficient power to cut all wood types. A 14 HP petrol engine is also available on the LT15START.

Logs are secured to the bed by the three standard log clamps and six adjustable backstops. The head height is precisely positioned by a hand crank and cutting is accomplished by steadily pushing the sawmill head along the length of the log with light pressure. Once the cut is completed, the head is raised, and then pulled back and lowered into position for the next cut.

A water tank feeds lubrication directly to the blade to improve cutting performance and keep the blade clean. The adjustable blade guide arm keeps the blade well-supported while cutting various sized material. Blade tension is easily adjusted, and keeps the blade at the proper tension for cutting.

Popular Options

Optional log loading ramps aid loading large logs with spring loaded brackets. Easily cut longer logs by adding additional bed extensions.

Mobile Version LT15START Sawmill

LT15START Sawmill is Also Available in Mobile Version.

Non-braked single axle 750kg

Read More
Videos LT15START Sawmill
Features LT15START Sawmill

Specifications LT15START Sawmill
Specifications
Power
Power 5.5 kW Electric
7.5 kW Electric
14 HP Petrol (KOHLER Command PRO CH440)
Cutting Capacity
Max. Log Diameter 70 cm
Max. Log Length 5.2 m (3 segments 1,95 m each)
Max. Width of Cut 64 cm
Max. Cant Width 59 cm
Max. Depth of Cut 27 cm
Head Features and Options
Head Up/Down Hand Crank
Electric (Chain)
Head Forward/Reverse Manual Push
Blade Guide Arm Manual
Blade Lubrication Manual Valve
Blade Tension System Screw with Gauge
Sawdust Collection Port Diameter 101.6 mm (4'')
Blade
Length 4010 mm
Width 32 mm
Blade Wheels
Blade Wheel Diameter 483 mm
Blade Wheel Type Belted
Blade Wheel Material Cast Iron
Bed Features and Options
Bed Construction Twin Rail
Bed Extensions Additional Bed Sections: 1.95 m or 2.7 m
Log Handling
Manual S3 Bed (3 segments 1.95 m each): 6 Side Supports, 3 Manual Log Clamps
Log wedge
Sawmill Features and Options
Frame Construction Semi-Cantilever
Power Requirements 400 V / 11 A (5.5 kW)
400 V / 16 A (7.5 kW)
Standards CE
Options Log Loading Ramps
Cant Hook
